      Worse case. Amazon extrude and an engraved sports figure. CADQuader didn't like this one much. But as an exported .obj Blender didnt have any issues.
    • Carlosan
    • Jakejazz
      Thank you Carlosan. However, the app is not reponding as I remember. Perhaps the autosnap function is improved and the vertices rarely stray form the reference mesh surface, so this ability is no longer required.
    • Carlosan
      In 3DCoat, you can align vertices in the Retopo workspace using the Align Vertices tool, the Transform tool (scaling to zero), or Symmetry Snapping depending on your goal   1. Using the Dedicated Align Vertices Tool Introduced in 3DCoat 2021, this tool flattens selected vertices along an average plane or line.  Select Vertices. Switch to Select mode, set the selection type to Vertices, and highlight the points you want to align. (Tip: In Edge mode, Shift-click an edge to select an entire loop, then switch to Vertex mode).  Activate the Tool. Right-click in the viewport and select Align Vertices from the context menu.  Preview and Apply. Red dots will show the target average positions while green lines indicate the offset. Click Apply in the tool options panel to snap them into alignment.  2. Straightening Along a Specific Axis (Transform Scale) If you want to make an edge loop completely flat along the X, Y, or Z axis, scaling via the Transform gizmo is the fastest method.  Select the Loop. Select the vertices or edge loop you need to straighten. Open Transform. Right-click and choose Transform. Flatten the Axis. Click and drag the scale handle (the square/cube widget) for the axis you want to flatten until it scales down to 0.  3. Aligning Centerline Vertices to the Symmetry Plane To ensure center vertices sit cleanly at 0 without crossing over:  Enable Symmetry. Press S to open the Symmetry panel, turn on Symmetry, and choose your axis.  Snap to Zero. Use the Move/Weld or Brush tool with symmetry active. Moving vertices close to the symmetry plane will snap them directly onto the 0 line.  Manual Zeroing. Alternatively, select the centerline vertices, open the Transform tool, reset the gizmo axis if needed, and manually type 0 into the position field for that axis in the tool options panel.  4. Re-snapping Vertices to the Reference Mesh If vertices drift off the underlying high-poly sculpt: Enable Auto-Snap. Ensure Auto-Snap is toggled on in the top Retopo toolbar. Relax or Nudge. Use the Brush tool (or hold Shift to Relax) and lightly tap or stroke over the misaligned vertices to pull them back onto the reference surface.
    • wendallhitherd
      bug related to Live Smooth Live smooth + symmetry = parts of live smooth object will be shrunk to zero
    • Britain
      If I have separate solids, if I export as an .obj, and the file has 3 different entities the file will contain 3 .obj files.  This file is one, export as an .obj its one yet you can see the seams of 3 enities. Instead of quading the file as one , its quading each separately. Im not familular with Plasticity software but most cad requires some knitting of parts to have only one solid. EDIT: tested again with just connected bodies. These work ok. Its surfaces which have the issue.        2_body.sc
    • Gorbatovsky
      There is an issue with importing in the program CADQuader. I imported your file into the Plasticity software. Then, I exported it from there as a STEP file. Following this, all the surfaces are now perceived in CADQuader as a single entity—a "surfaces Set."
    • Britain
      Each of the surfaces are connected together and create on body. The edges in the CADQuader are treating the edges as being separate not together. I can separate all the surfaces into separate bodies, import into the CADQuader and I get the same quad results as when they are connected into one body. That is each of the 5 surfaces (3 Body) are treated separately. For me it would seem if you have one body with multiple surfaces, those surfaces would be 1 surface. EDIT: For hard surface object this wouldn't be in issue but for surface such as car hoods and panels it will be.
    • Gorbatovsky
      A mesh is generated for each surface independently of the other surfaces. For the solid body, the edges are joined together.
    • webmaster
      Meet the Alpha Version of CADQuader — our brand-new tool for converting STEP files into quad meshes.View the full article
    • Gorbatovsky
      This is by design. Menus are not displayed in full-screen mode. I just discovered that the command search feature Ctrl+F  does not work in full-screen mode.
    • Britain
      If I use 3 bodies and connect them with a blend the quads break. The quads on both the 2 body and 3 body follow the edge connections. Is there a way to stop following the edge connection on the inside so that a better quad might happen? Its almost as if the edge connections are treated as a sharp edge.
    • Britain
      Using surface tools. If I use 2 Bodies and then connect them using a blend I get descent quads.
    • webmaster
      Part 1: Sculpting a Lion Statue in 3DCoat — Part 1 #3dcoat #sculpting #3dsculpting #digitalartView the full article
    • webmaster
      Part 2: Sculpting a Lion Statue in 3DCoat — Part 2 #3dcoat #sculpting #3dsculpting #digitalartView the full article
    • Alexander Lamar
      Thank you! I had to use the trial as I only have a 2024 license, but I was able to verify that the crash is fixed in the latest 3DCoatTextura. Appreciate it. I am noticing one issue now where the projection is positioned up and to the left in the external editor -- I'm attaching an image of the 3DCoat viewport of an object, and then the resulting projection in Photoshop. I would expect the projection to match the 3DCoat viewport (which is how it worked I believe in previous version) -- not the worst bug, but it results in some cropping and can make editing a little difficult.
    • SERGYI
      I have reproduced the crash when opening the external editor on macOS 27. The issue was obsolete code that didn't work on macOS 27. I have replaced that code with a modern alternative. Then I rebuilt and re-uploaded 3DCoat 2026.26 for macOS: https://pilgway.com/~sergyi/links-macOS.html Edit > Sync Layer w/ Ext. Editor and Edit Projections in Ext. Editor are working now on macOS 27. Please note that Smart/Node Materials are not working in this build because of ongoing global changes in 3DCoat source code.
    • Ctc_nick
      You can try this: 1. Set your clusters. 2. Click Set Seams. 3. Click "Intersections" --->This makes the seams recognized by Unwrap 4. Unwrap. I tested a Cube with six faces: perfect, Cylinder total chaos -It had worked better when there were already some basic seams, Capsule okay. I assume the tool does not like triangles for calculation very much.
    • Britain
      Interesting. Parametric modeling dosen't care about normals. Attached picture shows Planes with boundary connections. The boundaries normals are correct but the planes are not. When they are stitched together to start solid process every normal is flipped negative. Running the CadQuader it doesn't care but the normals when exported .obj file will have the normals that the step file normals are. Perhaps there should be a check to show the normals and a process to correct them before export to obj?  Hood.step
